5-Axis CNC Machining

Unlock unlimited manufacturing possibilities with our state-of-the-art 5-axis machining centers. Achieve complex geometries, superior surface finishes, and unmatched precision in a single setup.

5-Axis CNC Machine

DMG MORI DMU 50

  • Simultaneous 5-axis machining
  • Maximum workpiece size: 500 x 450 mm
  • Spindle speed: 20,000 RPM

Hermle C42U

  • Dynamic 5-axis processing
  • Maximum workpiece size: 800 x 800 mm
  • Spindle speed: 18,000 RPM

Technical Specifications

Axis Configuration

Linear Axes
X, Y, Z travel: 500/450/400 mm
Rotary Axes
A-axis: -110° to +110°, C-axis: 360°
Positioning Accuracy
±0.003 mm

Machining Capabilities

Maximum Speed
20,000 RPM
Tool Magazine
60 positions with chip-to-chip < 2.5s
Cutting Feed Rate
Up to 40m/min

Control System

CNC Control
Heidenhain TNC 640
Programming
CAM-optimized with RTCP
Simulation
Real-time collision monitoring

Industry Applications

Aerospace

Complex structural components and turbine parts requiring high precision and advanced materials processing.

Key Components:
Turbine bladesImpellersComplex housingsStructural components
Materials:
TitaniumInconelAluminum alloys

Medical

Precision medical devices and implants with intricate geometries and biocompatible materials.

Key Components:
Custom implantsSurgical instrumentsOrthopedic devicesDental components
Materials:
TitaniumStainless SteelPEEK

Automotive

High-performance automotive parts requiring complex surfacing and tight tolerances.

Key Components:
Cylinder headsSuspension componentsCustom racing partsPrototype components
Materials:
AluminumSteel alloysCarbon fiber composites

Technical Advantages

1

Single Setup Manufacturing

Complete complex parts in one setup, reducing errors and improving accuracy

  • Eliminated transfer errors
  • Reduced setup time
  • Improved geometric accuracy
  • Better surface finish
2

Complex Geometry Capability

Machine intricate shapes and undercuts impossible with conventional machining

  • Deep cavity machining
  • Compound angles
  • Sculptured surfaces
  • Undercut features
3

Advanced Process Control

Real-time monitoring and adaptive machining capabilities

  • In-process verification
  • Automatic tool compensation
  • Dynamic collision avoidance
  • Optimized tool paths

Quality Assurance

Comprehensive quality control process ensuring precise, reliable results

In-Process Measurement

  • Renishaw probing systems
  • Laser tool measurement
  • Real-time monitoring

Post-Process Verification

  • Zeiss CMM inspection
  • Surface roughness testing
  • Material certification

Documentation

  • First article inspection
  • Statistical process control
  • Digital twin verification
ISO 9001:2015
Quality Management System
AS9100D
Aerospace Quality Standard

Technical Expertise

CAD/CAM Programming

  • Hypermill optimization
  • Trochoidal toolpaths
  • Dynamic roughing strategies

Material Expertise

  • High-temperature alloys
  • Exotic materials
  • Composite materials

Process Optimization

  • Cutting parameter optimization
  • Tool life management
  • Surface finish optimization
