Custom CPVC Parts Manufacturing

Chemical-Resistant Industrial Solutions

Expert manufacturing of Chlorinated Polyvinyl Chloride (CPVC) components engineered for superior chemical resistance, high-temperature stability, and excellent fire safety in demanding industrial environments.

Temperature Rating

Up to 200°F (93°C)

Chemical Resistance

Excellent

Fire Rating

UL 94 V-0

CPVC Parts Manufacturing

Technical Specifications

Industry-Leading CPVC Performance Metrics

Mechanical Properties

Tensile Strength8,000 psi (55 MPa)
Flexural Modulus4.23 x 10⁵ psi
Impact Strength1.5 ft-lb/in
Specific Gravity1.55

Thermal Properties

Heat Deflection Temperature217°F (103°C)
Thermal Conductivity0.95 BTU/hr/ft²/°F/in
Coefficient of Expansion3.8 x 10⁻⁵ in/in/°F
Maximum Service Temperature200°F (93°C)

Chemical Resistance

AcidsExcellent
BasesExcellent
SaltsExcellent
Oxidizing AgentsGood to Excellent

Industrial Applications

CPVC components excel in demanding industrial environments where chemical resistance and temperature stability are critical:

Chemical Processing

Equipment for handling aggressive chemicals

  • Chemical storage tanks
  • Process piping systems
  • Pump components
  • Valve bodies

Water Treatment

Components for water purification systems

  • Filter housings
  • Distribution manifolds
  • Chlorination equipment
  • Flow control devices

Industrial Plumbing

High-performance plumbing solutions

  • Hot water distribution
  • Chemical waste systems
  • Ventilation components
  • Drainage systems

Manufacturing Capabilities

Our advanced CPVC manufacturing processes ensure precise, reliable components:

Precision Machining

  • Tolerance control to ±0.005"
  • Complex geometries
  • Surface finish Ra 32-63
  • Custom threading options

Injection Molding

  • High-volume production
  • Consistent part quality
  • Complex shapes possible
  • Cost-effective solutions

Fabrication

  • Custom assemblies
  • Welded constructions
  • Size range: 0.5" to 24"
  • Various joining methods

Quality Standards & Testing

Comprehensive quality assurance for every CPVC component:

Material Certification

  • ASTM D1784 compliance
  • NSF/ANSI 61 certification
  • UL 94 V-0 fire rating
  • Chemical composition analysis

Physical Testing

  • Hydrostatic pressure testing
  • Impact resistance verification
  • Heat deflection testing
  • Dimensional stability checks

Performance Validation

  • Chemical resistance testing
  • Temperature cycling
  • Stress crack resistance
  • Long-term aging studies
ISO 9001:2015
NSF International
ASTM Standards
UL Certification

Design Considerations

Key factors for successful CPVC component design:

Temperature Management

  • Operating temperature limits
  • Thermal expansion allowance
  • Heat dissipation requirements
  • Temperature cycling effects

Chemical Compatibility

  • Media concentration levels
  • Exposure duration
  • Temperature effects on chemical resistance
  • Combined chemical effects

Mechanical Design

  • Pressure ratings
  • Structural support requirements
  • Joint design considerations
  • Installation stress factors

CPVC Material Advantages

Chemical Resistance

Superior resistance to acids, bases, and salts

  • Broad chemical compatibility
  • No corrosion concerns
  • Long service life
  • Minimal maintenance

Temperature Performance

Excellent high-temperature stability

  • Continuous use up to 200°F
  • Maintains properties at elevated temperatures
  • Good thermal insulation
  • Low thermal expansion

Safety Features

Inherent safety characteristics

  • Self-extinguishing
  • Low smoke emission
  • Non-toxic
  • Non-conductive

Start Your CPVC Project Today

Ready to leverage the exceptional chemical resistance and thermal stability of CPVC for your application? Our engineering team is here to help you optimize your design and choose the right manufacturing process.
