Stamped Heat Sinks

Economic solution for low to medium power applications

Stamped Heat Sinks

Overview

•

High-volume production capability

•

Cost-effective manufacturing

•

Consistent quality

•

Simple and reliable design

•

Quick production turnaround

•

Various mounting options

Technical Specifications

Material Properties

  • •Material: Aluminum 1100/3003
  • •Thermal Conductivity: 150-220 W/m·K
  • •Sheet Thickness: 0.5-2.0mm
  • •Surface Treatment: None/Anodized
  • •Material Temper: H14/H24

Manufacturing Specs

  • •Overall Size: Up to 150mm
  • •Fin Height: 5-25mm
  • •Stamping Tolerance: ±0.1mm
  • •Production Rate: Up to 1000/hour
  • •Mounting: Clip/Adhesive

Thermal Performance

  • •Thermal Resistance: 2.0-8.0°C/W
  • •Max Heat Load: 50W
  • •Operating Temp: -30°C to +120°C
  • •Recommended Airflow: 50-200 LFM
  • •Typical ΔT: 40-60°C

Common Applications

Consumer Electronics

  • •Power Adapters
  • •LED Drivers
  • •Small Power Supplies
  • •Audio Equipment
  • •IoT Devices

Automotive Electronics

  • •ECU Cooling
  • •LED Lighting
  • •Sensor Modules
  • •Battery Management
  • •Entertainment Systems

Industrial Controls

  • •Small Motors
  • •Power Regulators
  • •Control Circuits
  • •LED Indicators
  • •Sensor Systems

Design & Engineering Services

Product Design

  • •Thermal Requirements Analysis
  • •Material Selection
  • •Cost Optimization
  • •DFM Analysis
  • •Prototype Development

Tool Engineering

  • •Die Design
  • •Tool Life Analysis
  • •Process Optimization
  • •Quality Control
  • •Production Planning

Quality Assurance

  • •First Article Inspection
  • •In-Process Testing
  • •Thermal Validation
  • •Documentation
  • •Process Control
